MGA-61563-TR2G
RoHS
/
Package 6-TSSOP, SC-88, SOT-363
Category RF/IF and RFID / RF Amplifiers
Description
IC AMP W-CDMA 500MHZ-4GHZ SOT363
PDF
/
Buying Options
Total Price: USD $37.59
Unit Price: USD $37.5877
≥1 USD $37.5877
≥10 USD $30.8408
≥100 USD $29.8775
≥500 USD $28.91325
≥1000 USD $27.94995
Inventory: 5104
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Technical
P1dB 15.8dBm
Noise Figure 1.17dB ~ 1.8dB
Characteristic Impedance 50Ohm
RF Type W-CDMA, PCS
VSWR-Max 2
RF/Microwave Device Type WIDE BAND LOW POWER
Gain 15dB ~ 18dB
Power Dissipation 500mW
Nominal Supply Current 48mA
Operating Supply Current 48mA
Test Frequency 2GHz
Number of Channels 1
Power Supplies 3/5V
Frequency 500MHz~4GHz
Construction COMPONENT
Number of Functions 1
Voltage - Supply 3V 5V
Technology GAAS
Max Power Dissipation 500mW
Subcategory RF/Microwave Amplifiers
Max Operating Temperature 150°C
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Published 2006
Packaging Tape & Reel (TR)
Physical
Number of Pins 6
Package / Case 6-TSSOP, SC-88, SOT-363
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
