AVT-54689-BLKG
RoHS
/
Package TO-243AA
Category RF/IF and RFID / RF Amplifiers
Description
RF Amplifier InGAP HBT Gain Block 30dBm
PDF
/
Buying Options
Total Price: USD $3.22
Unit Price: USD $3.2224
≥1 USD $3.2224
≥10 USD $2.64385
≥100 USD $2.5612
≥500 USD $2.47855
≥1000 USD $2.3959
Inventory: 11303
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-243AA
Number of Pins 3
Technical
Packaging Tape & Reel (TR)
Published 2012
Part Status Obsolete
Moisture Sensitivity Level (MSL) 2 (1 Year)
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Max Power Dissipation 430mW
Voltage - Supply 4.5V~5.5V
Frequency 50MHz~6GHz
Operating Supply Voltage 5V
Number of Channels 1
Test Frequency 2GHz
Operating Supply Current 58mA
Nominal Supply Current 58mA
Power Dissipation 430mW
Gain 17.1dB
RF Type WiMAX / WiBro
Noise Figure 4.1dB
P1dB 17.4dBm
Dimensions
Height 1.6mm
Length 4.6mm
Width 2.6mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
