HMC6981LS6
RoHS
RoHS compliant
RoHS compliantPackage 16-LCQFN Exposed Pad
Category RF/IF and RFID / RF Amplifiers
Description
RF Amp Chip Single Power Amplifier 20000MHz 6.5V 16-Pin SMT Bulk
PDF
/
Buying Options
Total Price: USD $536.96
Unit Price: USD $536.9571
≥1 USD $536.9571
Inventory: 7902
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Technical
P1dB 33.5dBm
Characteristic Impedance 50Ohm
RF Type General Purpose
RF/Microwave Device Type WIDE BAND HIGH POWER
Gain 26dB
Operating Supply Current 1.1A
Test Frequency 17GHz~20GHz
Number of Channels 1
Power Supplies 5.5V
Pin Count 16
Base Part Number HMC698
Frequency 15GHz~20GHz
Construction COMPONENT
Number of Functions 1
Voltage - Supply 6V
Technology PHEMT
Max Power Dissipation 11.7W
Min Operating Temperature -55°C
Max Operating Temperature 85°C
Terminal Finish Tungsten/Nickel/Gold (W/Ni/Au)
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code no
Packaging Strip
Physical
Number of Pins 16
Surface Mount YES
Package / Case 16-LCQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 3 weeks ago)
Factory Lead Time 20 Weeks
