HMC637A
RoHS
RoHS compliant
RoHS compliantPackage Die
Category RF/IF and RFID / RF Amplifiers
Description
IC RF AMP VSAT 0HZ-6GHZ DIE
PDF
/
Buying Options
Total Price: USD $183.87
Unit Price: USD $183.8668
≥1 USD $183.8668
≥10 USD $164.8459
Inventory: 710
Minimum: 1
-
+
Technical Details
Technical
Gain 13dB
Current - Supply 400mA
Operating Temperature (Min) -55°C
Operating Temperature (Max) 85°C
Pin Count 0
Base Part Number HMC637
Frequency 0Hz~6GHz
Construction COMPONENT
Voltage - Supply 5V
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
Packaging Tray
P1dB 29dBm
Noise Figure 12dB
Input Power-Max (CW) 25dBm
RF Type VSAT
RF/Microwave Device Type WIDE BAND MEDIUM POWER
Physical
Number of Pins 0
Package / Case Die
Mounting Type Surface Mount
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 2 weeks ago)
Factory Lead Time 12 Weeks
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
