DAT72415P
RoHS
RoHS compliant
RoHS compliantPackage /
Category Relays / Reed Relays
Description
RELAY REED SPST-NO 2A 24V
PDF
/
Buying Options
Total Price: USD $76.14
Unit Price: USD $76.1376
≥1 USD $76.1376
≥10 USD $72.52784
≥100 USD $69.206896
≥500 USD $67.172248
Inventory: 71
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material Tungsten (W)
Mount Chassis Mount, Panel
Mounting Type Chassis Mount
Technical
Operating Temperature -20°C~70°C
Packaging Tray
Published 2007
Series DA
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Additional Feature PANEL MOUNTABLE
HTS Code 8536.49.00.50
Voltage - Rated DC 24V
Depth 15.8mm
Current Rating 2A
Termination Style Solder Turret
Contact Resistance 250mOhm
Contact Current(DC)-Max 2A
Number of Poles 1
Throw Configuration SPST
Contact Form SPST-NO (1 Form A)
Relay Type Reed
Contact Current(AC)-Max 2A
Coil Resistance 350Ohm
Operate Time 3ms
Coil Voltage 24VDC
Coil Type Non Latching
Switching Voltage 10000VAC 10000VDC -Max
Coil Current 68.6mA
Release Time 2ms
Must Operate Voltage 20VDC
Must Release Voltage 4VDC
Contact/Output Supply Type AC/DC
Relay Action MOMENTARY
Coil Voltage (DC) 24V
Coil/Input Supply Type DC
Switching Current 2A
Dimensions
Height 18.5mm
Length 60mm
Compliance
RoHS Status ROHS3 Compliant
