DAT200-24

Cynergy 3
RoHS
RoHS RoHS compliant
Package /
Category Relays / Reed Relays
Description RELAY REED SPST-NO 3A 24V
PDF
/
Buying Options
Total Price: USD $114.61
Unit Price: USD $114.613544
≥1 USD $114.613544
≥200 USD $45.732246
≥500 USD $44.20403
≥1000 USD $43.4478
Inventory: 8909
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC No SVHC

Dimensions

Width 15.8mm
Length 60mm
Height 18.5mm

Technical

Switching Current 3A
Coil Voltage (DC) 24V
Must Release Voltage 4VDC
Coil Power 738mW
Must Operate Voltage 20VDC
Release Time 1ms
Coil Current 31mA
Switching Voltage 2500VAC 2500VDC -Max
Coil Type Non Latching
Coil Voltage 24VDC
Operate Time 6ms
Coil Resistance 780Ohm
Relay Type Reed
Contact Form SPST-NO (1 Form A)
Throw Configuration SPST
Contact Resistance 600mOhm
Termination Style PC Pin
Depth 15.8mm
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series D200
Published 2012
Packaging Bulk
Operating Temperature -20°C~70°C

Physical

Mounting Type Through Hole
Mount PCB, Through Hole
Contact Material Tungsten (W)

Supply Chain

Factory Lead Time 8 Weeks
