DSS41A12
RoHS
/
Package SIP
Category Relays / Reed Relays
Description
RELAY REED SPST 500MA 12V
PDF
/
Buying Options
Total Price: USD $1.33
Unit Price: USD $1.32715
≥1 USD $1.32715
≥10 USD $1.08965
≥100 USD $1.05545
≥500 USD $1.02125
≥1000 USD $0.98705
Inventory: 25007
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Body Height 7.62mm
Technical
Coil/Input Supply Type DC
Coil Voltage (DC) 12V
Relay Action MOMENTARY
Contact/Output Supply Type AC/DC
Contact Voltage(AC)-Max 200V
Operating Frequency-Max 0.0005MHz
Must Release Voltage 1.5VDC
Coil Power 144mW
Contact Rating (Current) 500mA
Must Operate Voltage 8.6VDC
Contact (DC) Max Rating R Load .5A@200VDC
Release Time 0.5 ms
Coil Current 12mA
Switching Voltage 200VAC 200VDC -Max
Coil Type Non Latching
Coil Voltage 12VDC
Operate Time 0.5ms
Contact (AC) Max Rating R Load .5A@200VAC
Coil Resistance 1kOhm
Relay Type Reed
Contact Form SPST-NO (1 Form A)
Throw Configuration SPST
Electrical Life 500000000 Cycle(s)
Contact Voltage(DC)-Max 200V
Sealing HERMETICALLY SEALED
Physical Dimension 19.05mm x 5.08mm x 7.62mm
Body Breadth 5.08 mm
Body Length or Diameter 19.05mm
Termination Style PC Pin
Reference Standard UL
HTS Code 8536.49.00.50
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series DSS4
Published 2001
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Package / Case SIP
Mounting Type Through Hole
Mount Through Hole
