9104-12-11
RoHS
RoHS compliant
RoHS compliantPackage SIP
Category Relays / Reed Relays
Description
REED RELAY, SPST-NO, 12VDC, 0.5A, THD
PDF
/
Buying Options
Total Price: USD $10.18
Unit Price: USD $10.1816
≥1 USD $10.1816
≥10 USD $9.04787
≥100 USD $8.595646
≥500 USD $8.143256
≥1000 USD $7.690795
≥3000 USD $7.012201
Inventory: 13216
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Length - Termination 0.0031 inch
Width 6.22mm
Height 8.13mm
Technical
Contact (DC) Max Power Rating R Load 10W@1000VDC
Switching Current 500mA
Dielectric Strength Between Coil and Contacts 3000 Vrms
Input Switching Control Type Random
Dielectric Strength Between Open Contacts 2000 Vrms
Coil Voltage (AC) 12V
PCB Hole Count 4
Coil/Input Supply Type DC
Coil Voltage (DC) 12V
Relay Action LATCHED
Contact/Output Supply Type AC/DC
Contact Voltage(AC)-Max 1000V
Must Release Voltage 1VDC
Must Operate Voltage 9VDC
Contact (DC) Max Rating R Load 0.5A@1000VDC
Release Time 0.5ms
Coil Current 24mA
Switching Voltage 1000VAC 1000VDC -Max
Coil Type Non Latching
Coil Voltage 12VDC
Operate Time 0.75ms
Contact (AC) Max Rating R Load 0.5A@1000VAC
Coil Resistance 500Ohm
Contact Current(AC)-Max 0.5A
Relay Type Reed
Contact Form SPST-NO (1 Form A)
Throw Configuration SPST
Electrical Life 300000000 Cycle(s)
Contact Voltage(DC)-Max 1000V
Sealing HERMETICAL
Contact Current(DC)-Max 0.5A
Insulation Resistance 100GOhm
Contact Resistance 200mOhm
Approval Agency UL
Termination Style PC Pin
Reference Standard UL
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Termination PC Pin
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Diode, EMI Shielded
JESD-609 Code e3
Series 9104
Published 2006
Packaging Bulk
Operating Temperature -20°C~85°C
Physical
Package / Case SIP
Mounting Type Through Hole
Mount Through Hole
Contact Material Ruthenium
Supply Chain
Factory Lead Time 24 Weeks
