8021-05-01
RoHS
/
Package /
Category Relays / Reed Relays
Description
e3 MOMENTARY DC RoHS Compliant Reed Relay 1ms -20C~85C 6.58mm 200Ohm
PDF
/
Buying Options
Total Price: USD $8.05
Unit Price: USD $8.046764
≥1 USD $8.046764
≥200 USD $3.211353
≥500 USD $3.103696
≥1000 USD $3.05118
Inventory: 983
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Body Height 6.6mm
Technical
Coil/Input Supply Type DC
Coil Voltage (DC) 5V
Relay Action MOMENTARY
Contact Voltage(AC)-Max 200V
Must Release Voltage 0.5VDC
Coil Power 125mW
Contact Rating (Current) 500mA
Must Operate Voltage 3.8VDC
Contact (DC) Max Rating R Load .5A@200VDC
Release Time 1ms
Coil Current 25mA
Switching Voltage 200VAC 200VDC -Max
Coil Type Non Latching
Coil Voltage 5VDC
Operate Time 0.5ms
Contact (AC) Max Rating R Load .5A@200VAC
Coil Resistance 200Ohm
Relay Type Reed
Contact Form SPST-NC (1 Form B)
Throw Configuration SPST
Electrical Life 500000000 Cycle(s)
Contact Voltage(DC)-Max 200V
Sealing HERMETICALLY SEALED
Physical Dimension 19.5mm x 6.58mm x 6.6mm
Body Breadth 6.58 mm
Body Length or Diameter 19.5mm
Termination Style PC Pin
Reference Standard UL
HTS Code 8536.49.00.50
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Diode
JESD-609 Code e3
Series 8000
Published 2006
Packaging Tube
Operating Temperature -20°C~85°C
Physical
Mounting Type Through Hole
Mount Through Hole
