7301-05-1010
RoHS
/
Package /
Category Relays / Reed Relays
Description
RELAY REED SPST 500MA 5V
PDF
/
Buying Options
Total Price: USD $26.81
Unit Price: USD $26.813357
≥1 USD $26.813357
≥200 USD $10.698822
≥480 USD $10.341713
≥1000 USD $10.164472
Inventory: 1484
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Technical
Coil Voltage (DC) 5V
Must Release Voltage 0.4VDC
Contact Rating (Current) 500mA
Must Operate Voltage 3.75VDC
Release Time 0.1ms
Coil Current 28.6mA
Switching Voltage 500VAC 500VDC -Max
Coil Type Non Latching
Coil Voltage 5VDC
Operate Time 1ms
Coil Resistance 175Ohm
Relay Type Reed
Contact Form SPST-NO (1 Form A)
Throw Configuration SPST
Contact Resistance 150mOhm
Termination Style PC Pin
Terminal Finish Matte Tin (Sn)
Termination PC Pin
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Electrostatic Shield
JESD-609 Code e3
Series 7000
Published 2012
Packaging Bulk
Operating Temperature -20°C~85°C
Physical
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 20 Weeks
