7201-05-1100
RoHS
RoHS compliant
RoHS compliantPackage /
Category Relays / Reed Relays
Description
RELAY REED SPST 1A 5V
PDF
/
Buying Options
Total Price: USD $35.97
Unit Price: USD $35.9744
≥1 USD $35.9744
≥10 USD $34.18008
≥100 USD $32.380832
≥500 USD $30.58176
Inventory: 140
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 22 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Technical
Operating Temperature -20°C~85°C
Packaging Bulk
Published 2011
Series 7000
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
Termination PC Pin
Terminal Finish Matte Tin (Sn)
Termination Style PC Pin
Contact Resistance 100mOhm
Throw Configuration SPST
Contact Form SPST-NO (1 Form A)
Relay Type Reed
Coil Resistance 70Ohm
Operate Time 2ms
Coil Voltage 5VDC
Coil Type Non Latching
Switching Voltage 500VAC 500VDC -Max
Coil Current 71.4mA
Release Time 1ms
Must Operate Voltage 3.75VDC
Contact Rating (Current) 1A
Must Release Voltage 0.4VDC
Coil Voltage (DC) 5V
Compliance
RoHS Status ROHS3 Compliant
