7103-24-1000
RoHS
/
Package /
Category Relays / Reed Relays
Description
Reed Relays 3PST-NO 0.5A 24VDC 2.4KOhm Thru-Hole
PDF
/
Buying Options
Total Price: USD $25.67
Unit Price: USD $25.671134
≥1 USD $25.671134
≥200 USD $10.243246
≥500 USD $9.900579
≥1000 USD $9.732528
Inventory: 6815
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Technical
Operating Temperature -20°C~85°C
Packaging Bulk
Published 2012
Series 7000
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Termination PC Pin
Terminal Finish Matte Tin (Sn)
Termination Style PC Pin
Contact Resistance 150mOhm
Throw Configuration 3PST
Contact Form 3PST-NO (3 Form A)
Relay Type Reed
Coil Resistance 2.4kOhm
Operate Time 1ms
Coil Voltage 24VDC
Coil Type Non Latching
Switching Voltage 200VAC 200VDC -Max
Coil Current 10mA
Release Time 0.1ms
Must Operate Voltage 18VDC
Contact Rating (Current) 500mA
Must Release Voltage 2VDC
Coil Voltage (DC) 24V
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
