7101-05-1011
RoHS
/
Package /
Category Relays / Reed Relays
Description
e3 MOMENTARY DC AC/DC Reed Relay 0.1ms -20C~85C 9.52mm 300Ohm
PDF
/
Buying Options
Total Price: USD $25.59
Unit Price: USD $25.59236
≥1 USD $25.59236
≥200 USD $10.211736
≥480 USD $9.870382
≥1000 USD $9.702331
Inventory: 6795
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Technical
Operating Temperature -20°C~85°C
Packaging Bulk
Published 2012
Series 7000
JESD-609 Code e3
Feature Diode, Electrostatic Shield
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
Termination PC Pin
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Additional Feature SHIELDED
Termination Style PC Pin
Body Length or Diameter 30.23mm
Contact Resistance 150mOhm
Sealing HERMETICALLY SEALED
Contact Voltage(DC)-Max 200V
Electrical Life 1000000000 Cycle(s)
Throw Configuration SPST
Contact Form SPST-NO (1 Form A)
Relay Type Reed
Coil Resistance 300Ohm
Contact (AC) Max Rating R Load .5A@200VAC
Operate Time 1ms
Coil Voltage 5VDC
Coil Type Non Latching
Switching Voltage 200VAC 200VDC -Max
Coil Current 16.7mA
Release Time 0.1ms
Contact (DC) Max Rating R Load .5A@200VDC
Must Operate Voltage 3.75VDC
Contact Rating (Current) 500mA
Coil Power 85mW
Must Release Voltage 0.4VDC
Contact Voltage(AC)-Max 200V
Contact/Output Supply Type AC/DC
Relay Action MOMENTARY
Coil Voltage (DC) 5V
Coil/Input Supply Type DC
Dimensions
Body Height 9.52mm
Compliance
RoHS Status RoHS Compliant
