3501-05-910

Coto Technology
RoHS
RoHS RoHS compliant
Package /
Category Relays / Reed Relays
Description RELAY REED SPST 500MA 5V
PDF
/
Buying Options
Total Price: USD $16.43
Unit Price: USD $16.4296
≥1 USD $16.4296
≥10 USD $15.61032
≥100 USD $14.789069
≥500 USD $14.46507
Inventory: 305
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 22 Weeks

Physical

Mount Through Hole
Mounting Type Through Hole

Technical

Operating Temperature -20°C~85°C
Packaging Tube
Published 2011
Series 3500
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
Termination PC Pin
Terminal Finish Matte Tin (Sn)
Termination Style PC Pin
Contact Resistance 300mOhm
Throw Configuration SPST
Contact Form SPST-NO (1 Form A)
Relay Type Reed
Coil Resistance 350Ohm
Operate Time 0.75ms
Coil Voltage 5VDC
Coil Type Non Latching
Switching Voltage 200VAC 200VDC -Max
Coil Current 14.3mA
Release Time 0.1ms
Must Operate Voltage 3.8VDC
Contact Rating (Current) 500mA
Must Release Voltage 0.4VDC
Coil Voltage (DC) 5V
Seal Rating Sealed - Hermetically

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
