2199170-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Spring Loaded
Description
TE CONNECTIVITY 2199170-1 Board-To-Board Connector, 6 Contacts, 1.6 mm, Surface Mount, 2 Rows
PDF
/
Buying Options
Total Price: USD $2.83
Unit Price: USD $2.831104
≥1 USD $2.831104
≥10 USD $2.670853
≥100 USD $2.519673
≥500 USD $2.377052
≥1000 USD $2.242502
Inventory: 6994
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Plating Thickness 200 nm
Contact Finish Thickness 3.94μin 0.10μm
Technical
Sealable No
Row Spacing 0.087 (2.20mm)
Housing Color Black
Number of Contacts 6
Contact Finish Gold
Pitch 0.063 1.60mm
Number of Rows 2
Number of Positions 6
Connector Type Compression Contact, Non-Gendered
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2013
Packaging Cut Tape (CT)
Physical
Housing Material Thermoplastic
Material Phosphor Bronze
Number of Pins 6
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Contact Material Bronze
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 11 Weeks
