SIR1-05-L-S

Samtec Inc.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Spring Loaded
Description Conn One Piece Interface RCP 5 POS 2.54mm Solder RA Thru-Hole Tube
PDF
/
Inventory: 8730
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 3 Weeks

Physical

Contact Material Bronze
Mount Through Hole
Mounting Type Surface Mount, Right Angle
Material Phosphor Bronze

Technical

Packaging Tube
Published 2015
Series SIR1
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Compression Contact, Non-Gendered
Number of Rows 1
Gender Female
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.100 2.54mm
Number of Conductors ONE
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Body Length or Diameter 0.6 inch
Number Of PCB Rows 1
Number of Contacts 5
PCB Contact Pattern RECTANGULAR
Body Breadth 0.236 inch
Body Depth 0.2 inch
Rated Current (Signal) 2.8A
Contact Pattern RECTANGULAR
Insulator Color BLACK

Dimensions

Contact Finish Thickness 10.0μin 0.25μm

Compliance

RoHS Status ROHS3 Compliant
