SIB-118-02-F-S
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Spring Loaded
Description
SIB ROHS3Compliant COMMERCIAL UL Spring Connector Compression Contact, Non-Gendered -55C 2.6A 0.264inch
PDF
/
Inventory: 9645
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material Bronze
Mount Surface Mount
Mounting Type Surface Mount
Material Phosphor Bronze
Technical
Packaging Tube
Published 2013
Series SIB
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Termination SMD/SMT
Connector Type Compression Contact, Non-Gendered
Number of Rows 1
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.100 2.54mm
Number of Conductors ONE
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Number Of PCB Rows 1
Number of Contacts 18
PCB Contact Pattern RECTANGULAR
Body Breadth 0.264 inch
Contact Gender MALE
Operating Temperature (Min) -55°C
Rated Current (Signal) 2.6A
Contact Pattern RECTANGULAR
Insulator Color BLACK
Dimensions
Contact Finish Thickness Flash
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
