SIB-110-02-F-S-LC
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Spring Loaded
Description
SAMTEC SIB-110-02-F-S-LC Board-To-Board Connector, SIB Series, 10 Contacts, 2.54 mm, Surface Mount, 1 Rows
PDF
/
Buying Options
Total Price: USD $16.65
Unit Price: USD $16.6459
≥1 USD $16.6459
≥10 USD $13.65815
≥100 USD $13.2316
≥500 USD $12.80505
≥1000 USD $12.37755
Inventory: 1504
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Contact Finish Thickness Flash
Length 50.8mm
Technical
Contact Pattern RECTANGULAR
Max Current Rating 2.2A
Rated Current (Signal) 2.6A
Housing Color Black
Body Breadth 0.264 inch
PCB Contact Pattern RECTANGULAR
Number of Contacts 10
Number Of PCB Rows 1
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Number of Conductors ONE
Depth 8.48mm
Orientation Straight
Pitch 0.100 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Gender Male
Number of Rows 1
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Connector Type Compression Contact, Non-Gendered
Termination Solder
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series SIB
Published 2006
Packaging Tube
Physical
Housing Material Polymer
Material Phosphor Bronze
Mounting Type Surface Mount
Mount Surface Mount
Contact Material Bronze, Copper
Supply Chain
Factory Lead Time 3 Weeks
