SIB-105-02-F-S
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Spring Loaded
Description
SIB ROHS3Compliant COMMERCIAL UL Spring Connector Compression Contact, Non-Gendered 125C 2.2A 8.48mm
PDF
/
Buying Options
Total Price: USD $4.02
Unit Price: USD $4.0216
≥1 USD $4.0216
≥10 USD $3.2824
≥100 USD $2.7808
≥500 USD $2.4728
≥1000 USD $2.035
Inventory: 99
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Contact Finish Thickness Flash
Length 12.7mm
Technical
Contact Pattern RECTANGULAR
Max Current Rating 2.2A
Rated Current (Signal) 2.6A
Housing Color Black
Contact Gender MALE
Body Breadth 0.264 inch
PCB Contact Pattern RECTANGULAR
Number of Contacts 5
Number Of PCB Rows 1
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Number of Conductors ONE
Depth 8.48mm
Orientation Straight
Pitch 0.100 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Number of Rows 1
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Connector Type Compression Contact, Non-Gendered
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series SIB
Published 2013
Packaging Tube
Physical
Housing Material Polymer
Material Phosphor Bronze
Mounting Type Surface Mount
Contact Material Bronze, Copper
Supply Chain
Factory Lead Time 3 Weeks
