SEI-125-02-GF-S-E-AB-TR

Samtec Inc.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Spring Loaded
Description SEI ROHS3Compliant COMMERCIAL UL Spring Connector Compression Contact, Non-Gendered -55C 2.3A 0.065inch
PDF
/
Inventory: 5989
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 3 Weeks

Physical

Contact Material Bronze
Mounting Type Surface Mount
Material Phosphor Bronze
Mounting Option 1 LOCKING
Board Mounting Option PEG

Technical

Packaging Tape & Reel (TR)
Published 2015
Series SEI
JESD-609 Code e4
Part Status Active
Termination Solder
Contact Pattern RECTANGULAR
Rated Current (Signal) 2.3A
Body Depth 0.24 inch
Operating Temperature (Min) -55°C
Body Breadth 0.065 inch
PCB Contact Pattern RECTANGULAR
Number of Contacts 25
Number Of PCB Rows 1
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Number of Conductors ONE
Reach Compliance Code not_compliant
Pitch 0.039 1.00mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Gender Male
Number of Rows 1
Connector Type Compression Contact, Non-Gendered

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Plating Thickness FLASH inch
Contact Finish Thickness 3.00μin 0.076μm
