SEI-110-02-GF-S-E-TR
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Spring Loaded
Description
SEI ROHS3Compliant COMMERCIAL UL Spring Connector Compression Contact, Non-Gendered -55C 2.3A 0.065inch
PDF
/
Inventory: 1820
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Plating Thickness FLASH inch
Contact Finish Thickness 3.00μin 0.076μm
Technical
Contact Pattern RECTANGULAR
Rated Current (Signal) 2.3A
Body Depth 0.24 inch
Operating Temperature (Min) -55°C
Body Breadth 0.065 inch
PCB Contact Pattern RECTANGULAR
Number of Contacts 10
Number Of PCB Rows 1
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Number of Conductors ONE
Pitch 0.039 1.00mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Gender Male
Number of Rows 1
Connector Type Compression Contact, Non-Gendered
Termination Solder
Part Status Active
JESD-609 Code e4
Series SEI
Published 2015
Packaging Tape & Reel (TR)
Physical
Mounting Option 1 LOCKING
Material Phosphor Bronze
Mounting Type Surface Mount
Contact Material Bronze
Supply Chain
Factory Lead Time 3 Weeks
