SEI-105-02-GF-S-E-AT-TR
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Spring Loaded
Description
SEI ROHS3Compliant COMMERCIAL UL Spring Connector Compression Contact, Non-Gendered 2.3A 0.24inch
PDF
/
Inventory: 2447
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material Bronze
Mounting Type Surface Mount
Material Phosphor Bronze
Mounting Option 1 LOCKING
Board Mounting Option PEG
Technical
Packaging Tape & Reel (TR)
Published 2015
Series SEI
JESD-609 Code e4
Part Status Active
Termination Solder
Connector Type Compression Contact, Non-Gendered
Number of Rows 1
Gender Male
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.039 1.00mm
Number of Conductors ONE
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Number Of PCB Rows 1
Number of Contacts 5
PCB Contact Pattern RECTANGULAR
Body Depth 0.24 inch
Rated Current (Signal) 2.3A
Contact Pattern RECTANGULAR
Dimensions
Contact Finish Thickness 3.00μin 0.076μm
Plating Thickness FLASH inch
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
