OPP-07-01-T-S-AD
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Spring Loaded
Description
Spring Loaded Rectangular Connector
PDF
/
Buying Options
Total Price: USD $3.63
Unit Price: USD $3.6256
≥1 USD $3.6256
≥10 USD $2.9568
≥100 USD $2.508
≥500 USD $2.226418
≥1000 USD $2.079
Inventory: 104
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material Copper
Mount Surface Mount
Mounting Type Surface Mount
Material Beryllium Copper
Housing Material Polymer
Technical
Packaging Tube
Published 2002
Series OPP
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Compression Contact, Non-Gendered
Max Operating Temperature 105°C
Min Operating Temperature -55°C
Number of Rows 1
Gender Male
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.100 2.54mm
Orientation Right Angle
Depth 9.32mm
Number of Conductors ONE
Contact Finish Tin
Reliability COMMERCIAL
Number of Contacts 7
Body Breadth 0.26 inch
Max Voltage Rating (AC) 600V
Max Current Rating 8.3A
Dielectric Withstanding Voltage 600VAC V
Insulator Color BLACK
Dimensions
Length 18.54mm
Compliance
RoHS Status ROHS3 Compliant
