8PM-11-0009-02-131
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Spring Loaded
Description
CONN SPRING PISTON 9POS R/A SMD
PDF
/
Inventory: 6904
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount, Right Angle
Material Brass
Technical
Packaging Bulk
Published 2010
Series 8PM
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Piston
Number of Rows 1
Gender Male
Subcategory Headers and Edge Type Connectors
Pitch 0.100 2.54mm
Number of Conductors ONE
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Number Of PCB Rows 1
Number of Contacts 9
PCB Contact Pattern RECTANGULAR
Rated Current (Signal) 3A
Durability 50000 Cycles
Contact Pattern RECTANGULAR
Insulator Color BLACK
Dimensions
Contact Finish Thickness 10.0μin 0.25μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
