813-S1-064-10-014101
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Spring Loaded
Description
813 ROHS3Compliant COMMERCIAL UL Spring Connector Piston 50000Cycles 10mOhm -55C 3.5A
PDF
/
Inventory: 6163
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Through Hole
Material Brass
Technical
Packaging Bulk
Published 2012
Series 813
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type Piston
Number of Rows 2
Subcategory Headers and Edge Type Connectors
Pitch 0.100 2.54mm
Number of Conductors ONE
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Number Of PCB Rows 2
Number of Contacts 64
PCB Contact Pattern RECTANGULAR
Contact Gender MALE
Operating Temperature (Min) -55°C
Body Depth 0.157 inch
Rated Current (Signal) 3.5A
Contact Style RND PIN-SKT
Contact Resistance 10mOhm
Insulation Resistance 10000000000Ohm
Row Spacing 0.100 (2.54mm)
Termination Type SOLDER
Dielectric Withstanding Voltage 1400VAC V
Durability 50000 Cycles
Contact Pattern RECTANGULAR
Dimensions
Contact Finish Thickness 19.7μin 0.50μm
Length - Termination 0.118 inch
Compliance
RoHS Status ROHS3 Compliant
