813-S1-040-10-014101
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Spring Loaded
Description
Conn Socket Strip SKT 40 POS 2.54mm Solder ST Thru-Hole
PDF
/
Inventory: 7525
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Contact Material Copper
Mount Surface Mount
Mounting Type Through Hole
Material Brass
Housing Material Polychlorinated
Technical
Packaging Bulk
Published 2012
Series 813
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Piston
Number of Rows 2
Gender Female
Subcategory Headers and Edge Type Connectors
Pitch 0.100 2.54mm
Orientation Straight
Depth 5.08mm
Number of Conductors ONE
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Number Of PCB Rows 2
Number of Contacts 40
PCB Contact Pattern RECTANGULAR
Operating Temperature (Min) -55°C
Housing Color Black
Contact Style RND PIN-SKT
Contact Resistance 10mOhm
Insulation Resistance 10000000000Ohm
Row Spacing 0.100 (2.54mm)
Max Current Rating 3.5A
Durability 50000 Cycles
Contact Pattern RECTANGULAR
Dimensions
Length 50.8mm
Contact Finish Thickness 19.7μin 0.50μm
Compliance
RoHS Status ROHS3 Compliant
