813-S1-006-10-014101
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Spring Loaded
Description
Conn Spring Loaded Connector HDR 6 POS 2.54mm Solder ST Thru-Hole Box
PDF
/
Buying Options
Total Price: USD $3.83
Unit Price: USD $3.831518
≥1 USD $3.831518
≥10 USD $3.61464
≥100 USD $3.410038
≥500 USD $3.217016
≥1000 USD $3.034928
Inventory: 988
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness 19.7μin 0.50μm
Length 7.62mm
Height 4mm
Technical
Contact Pattern RECTANGULAR
Durability 50000 Cycles
Dielectric Withstanding Voltage 1400VAC V
Max Current Rating 3.5A
Max Voltage Rating (AC) 100V
Row Spacing 0.100 (2.54mm)
Insulation Resistance 10000000000Ohm
Contact Resistance 10mOhm
Contact Style RND PIN-SKT
Housing Color Black
PCB Contact Pattern RECTANGULAR
Number of Contacts 6
Number Of PCB Rows 2
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Number of Conductors ONE
Current Rating 3.5A
Depth 5.08mm
Orientation Straight
Pitch 0.100 2.54mm
Subcategory Headers and Edge Type Connectors
Voltage - Rated 150V
Gender Male
Number of Rows 2
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Connector Type Piston
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series 813
Published 2010
Packaging Bulk
Physical
Housing Material Polychlorinated
Material Brass
Mounting Type Through Hole
Mount Surface Mount, Through Hole
Contact Material Brass, Copper
Supply Chain
Factory Lead Time 10 Weeks
