811-SS-006-30-005101
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Spring Loaded
Description
811 ROHS3Compliant COMMERCIAL UL Spring Connector Piston 15mOhm 125C 3.5A 100V
PDF
/
Buying Options
Total Price: USD $3.21
Unit Price: USD $3.214712
≥1 USD $3.214712
≥10 USD $3.032741
≥100 USD $2.861085
≥500 USD $2.699136
≥1000 USD $2.546352
Inventory: 6997
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness 19.7μin 0.50μm
Length 15.24mm
Technical
Contact Pattern RECTANGULAR
Max Voltage Rating (DC) 150V
Max Current Rating 3.5A
Max Voltage Rating (AC) 100V
Contact Resistance 15mOhm
Contact Style RND PIN-SKT
Housing Color Black
PCB Contact Pattern RECTANGULAR
Number of Contacts 6
Number Of PCB Rows 1
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Number of Conductors ONE
Depth 2.54mm
Orientation Straight
Pitch 0.100 2.54mm
Subcategory Headers and Edge Type Connectors
Gender Male
Number of Rows 1
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Connector Type Piston
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series 811
Published 2012
Packaging Bulk
Physical
Housing Material Polychlorinated
Material Brass
Mounting Type Surface Mount
Mount Surface Mount
Contact Material Brass, Stainless Steel
Supply Chain
Factory Lead Time 10 Weeks
