811-S1-061-10-017101
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Spring Loaded
Description
811 ROHS3Compliant COMMERCIAL UL Spring Connector Piston 50000Cycles -55C 3.5A 0.24inch
PDF
/
Inventory: 3713
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Number of Conductors ONE
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Number Of PCB Rows 1
Number of Contacts 61
PCB Contact Pattern RECTANGULAR
Contact Gender MALE
Operating Temperature (Min) -55°C
UL Flammability Code 94V-0
Body Depth 0.24 inch
Rated Current (Signal) 3.5A
Contact Style RND PIN-SKT
Termination Type SOLDER
Durability 50000 Cycles
Contact Pattern RECTANGULAR
Pitch 0.100 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Additional Feature LOW PROFILE
Number of Rows 1
Connector Type Piston
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 811
Published 2012
Packaging Bulk
Dimensions
Contact Finish Thickness 19.7μin 0.50μm
Compliance
RoHS Status ROHS3 Compliant
Physical
Material Brass
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 10 Weeks
