811-S1-059-10-017101
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Spring Loaded
Description
CONN SPRING LOAD 59POS SNGL PCB
PDF
/
Inventory: 3454
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Material Brass
Technical
Packaging Bulk
Published 2012
Series 811
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type Piston
Number of Rows 1
Additional Feature LOW PROFILE
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.100 2.54mm
Number of Conductors ONE
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Body Length or Diameter 5.9 inch
Number Of PCB Rows 1
Number of Contacts 59
PCB Contact Pattern RECTANGULAR
Contact Gender MALE
Operating Temperature (Min) -55°C
UL Flammability Code 94V-0
Body Depth 0.24 inch
Rated Current (Signal) 3.5A
Contact Style RND PIN-SKT
Termination Type SOLDER
Durability 50000 Cycles
Contact Pattern RECTANGULAR
Dimensions
Contact Finish Thickness 19.7μin 0.50μm
Compliance
RoHS Status ROHS3 Compliant
