800-10-002-30-507101
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Spring Loaded
Description
Preci-Dip 2.54mm 2 Way 1 Row Straight Surface Mount Male Multiway Connector
PDF
/
Buying Options
Total Price: USD $0.7
Unit Price: USD $0.704
≥1 USD $0.704
≥10 USD $0.61512
≥100 USD $0.562144
≥500 USD $0.529232
≥1000 USD $0.507144
≥3000 USD $0.463091
Inventory: 4302
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Plating Thickness 9.8μin
Contact Finish Thickness 10.0μin 0.25μm
Length 5.08mm
Height 4mm
Technical
Contact Pattern RECTANGULAR
Max Current Rating 3.5A
Max Voltage Rating (AC) 100V
Contact Style RND PIN-SKT
Housing Color Black
Number of Contacts 2
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Number of Conductors ONE
Current Rating 3.5A
Depth 2.54mm
Orientation Straight
Pitch 0.100 2.54mm
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Voltage - Rated 150V
Gender Male
Number of Rows 1
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Connector Type Mating Target
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series 800
Published 2012
Packaging Bulk
Physical
Housing Material Polychlorinated
Material Brass
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
