838-22-018-10-001101
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Spring Loaded
Description
838 ROHS3Compliant COMMERCIAL UL Spring Connector Piston 1000000Cycles 2A 990VAC V 0.157inch
PDF
/
Inventory: 7889
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Mounting Type Through Hole
Material Copper Alloy
Mounting Option 1 LOCKING
Technical
Packaging Bulk
Series 838
JESD-609 Code e4
Part Status Active
Connector Type Piston
Number of Rows 2
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.079 2.00mm
Number of Conductors ONE
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Body Length or Diameter 0.709 inch
Number of Contacts 18
Body Breadth 0.157 inch
Contact Gender MALE
UL Flammability Code 94V-0
Body Depth 0.141 inch
Rated Current (Signal) 2A
Contact Style RND PIN-SKT
Insulation Resistance 10000000000Ohm
Row Spacing 0.079 (2.00mm)
Termination Type SOLDER
Dielectric Withstanding Voltage 990VAC V
Durability 1000000 Cycles
Contact Pattern RECTANGULAR
Dimensions
Contact Finish Thickness 10.0μin 0.25μm
Compliance
RoHS Status ROHS3 Compliant
