814-22-010-30-006101
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Spring Loaded
Description
CONN SPRING 10POS DUAL .370 SMD
PDF
/
Buying Options
Total Price: USD $7.11
Unit Price: USD $7.1104
≥1 USD $7.1104
≥10 USD $6.43192
≥100 USD $5.92834
≥500 USD $5.631894
≥1000 USD $5.039038
≥3000 USD $4.742646
Inventory: 98
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Material Copper Alloy
Technical
Packaging Bulk
Published 2007
Series 814
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Piston
Number of Rows 2
Additional Feature LOW PROFILE
HTS Code 8536.90.40.00
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature YES
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.100 2.54mm
Number of Conductors ONE
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Number Of PCB Rows 2
Lead Pitch 2.54mm
Number of Contacts 10
PCB Contact Pattern RECTANGULAR
Contact Gender MALE
UL Flammability Code 94V-0
Housing Color Black
Body Depth 0.198 inch
Rated Current (Signal) 2A
Contact Style RND PIN-SKT
Row Spacing 0.100 (2.54mm)
Dielectric Withstanding Voltage 990VAC V
Contact Pattern RECTANGULAR
Dimensions
Height 9.4mm
Length 12.7mm
Width 5.08mm
Contact Finish Thickness 20.0μin 0.51μm
Compliance
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
