813-22-028-30-002101
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Spring Loaded
Description
CONN SPRING CONT 28 POS .197 SMD
PDF
/
Inventory: 2788
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Material Copper Alloy
Technical
Packaging Tube
Published 2005
Series 813
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Piston
Number of Rows 2
Additional Feature LOW PROFILE
HTS Code 8536.90.40.00
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature YES
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.100 2.54mm
Number of Conductors ONE
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Body Length or Diameter 1.4 inch
Number Of PCB Rows 2
Number of Contacts 28
PCB Contact Pattern RECTANGULAR
Mating Information NO
Contact Gender MALE
UL Flammability Code 94V-0
Rated Current (Signal) 2A
Contact Style RND PIN-SKT
Insulation Resistance 10000000000Ohm
Row Spacing 0.100 (2.54mm)
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 1000VAC V
Durability 1000000 Cycles
Contact Pattern RECTANGULAR
Dimensions
Height 5mm
Contact Finish Thickness 20.0μin 0.51μm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
