813-22-002-30-004101
RoHS
RoHS compliant
RoHS compliantPackage SMD/SMT
Category Connectors, Interconnects / Rectangular Connectors - Spring Loaded
Description
CONN SPRING CONT 02 POS .236 SMD
PDF
/
Inventory: 7391
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SMD/SMT
Material Copper Alloy
Technical
Packaging Tube
Published 2005
Series 813
Contact Pattern RECTANGULAR
Durability 1000000 Cycles
Dielectric Withstanding Voltage 1000VAC V
Polarization Key POLARIZED HOUSING
Row Spacing 0.100 (2.54mm)
Insulation Resistance 10000000000Ohm
Contact Style RND PIN-SKT
Rated Current (Signal) 2A
UL Flammability Code 94V-0
Contact Gender MALE
Mating Information NO
PCB Contact Pattern RECTANGULAR
Number of Contacts 2
Number Of PCB Rows 2
Body Length or Diameter 0.1 inch
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Number of Conductors ONE
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.90.40.00
Additional Feature LOW PROFILE
Number of Rows 2
Connector Type Piston
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Contact Finish Thickness 20.0μin 0.51μm
Height 5.99mm
