811-22-063-30-000101

Mill-Max Manufacturing Corp.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Spring Loaded
Description 811 ROHS3Compliant COMMERCIAL UL Spring Connector Piston 20mOhm 2A 950VAC V 6.3inch
PDF
/
Inventory: 9423
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Surface Mount
Mounting Type Surface Mount
Material Copper Alloy

Technical

Packaging Tube
Published 2005
Series 811
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Piston
Number of Rows 1
Additional Feature LOW PROFILE
HTS Code 8536.90.40.00
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature YES
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.100 2.54mm
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Body Length or Diameter 6.3 inch
Number Of PCB Rows 1
Number of Contacts 63
PCB Contact Pattern RECTANGULAR
Contact Gender MALE
UL Flammability Code 94V-0
Rated Current (Signal) 2A
Contact Style RND PIN-SKT
Contact Resistance 20mOhm
Dielectric Withstanding Voltage 950VAC V
Contact Pattern RECTANGULAR

Dimensions

Height 3.48mm
Contact Finish Thickness 20.0μin 0.51μm
Plating Thickness 20μin

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
