811-22-053-30-002101
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Spring Loaded
Description
CONN SPRING CONT 53 POS .197 SMD
PDF
/
Inventory: 2311
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Material Copper Alloy
Technical
Packaging Tube
Published 2005
Series 811
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Piston
Number of Rows 1
Additional Feature LOW PROFILE
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature YES
Mixed Contacts NO
Option GENERAL PURPOSE
Contact Pattern RECTANGULAR
Dielectric Withstanding Voltage 950VAC V
Contact Resistance 20mOhm
Contact Style RND PIN-SKT
Rated Current (Signal) 2A
UL Flammability Code 94V-0
Contact Gender MALE
Mating Information NO
PCB Contact Pattern RECTANGULAR
Number of Contacts 53
Number Of PCB Rows 1
Body Length or Diameter 5.3 inch
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Pitch 0.100 2.54mm
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Plating Thickness 20μin
Contact Finish Thickness 20.0μin 0.51μm
Height 5mm
