811-22-064-30-007101
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Spring Loaded
Description
CONN SPRING CONT 64 POS .295 SMD
PDF
/
Inventory: 3681
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Length 162.56mm
Technical
Max Voltage Rating (AC) 100V
Contact Resistance 20mOhm
Housing Color Black
UL Flammability Code 94V-0
Contact Gender Male
Mating Information NO
Number of Contacts 64
Row Spacing - Mating 2.54 mm
Current Rating 3A
Depth 2.54mm
Orientation Straight
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.90.40.00
Additional Feature LOW PROFILE
Voltage - Rated 150V
Number of Rows 1
Connector Type BOARD STACKING CONNECTOR
ECCN Code EAR99
Termination SMD/SMT
Pbfree Code yes
JESD-609 Code e4
Published 2007
Physical
Housing Material Thermoplastic
Mount Surface Mount
Contact Plating Gold
Contact Material Brass
