70ADJ-6-ML1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Spring Loaded
Description
CONN MOD 6POS MALE SMD LOC PIN
PDF
/
Buying Options
Total Price: USD $2.53
Unit Price: USD $2.5344
≥1 USD $2.5344
≥10 USD $2.29988
≥100 USD $2.12784
≥500 USD $2.026464
≥1000 USD $1.773165
≥3000 USD $1.722494
Inventory: 6480
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Material Copper Alloy
Housing Material Thermoplastic
Technical
Packaging Tube
Published 2011
Series 70AD
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Compression Contact, Male
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Color Black
Number of Rows 1
Gender Male
Additional Feature ROHS COMPLIANT, LOW PROFILE
Subcategory Headers and Edge Type Connectors
Voltage - Rated DC 30V
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Option GENERAL PURPOSE
Pitch 0.157 4.00mm
Orientation Straight
Depth 11mm
Base Part Number 70ADJ
Number of Conductors ONE
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Number Of PCB Rows 2
Number of Contacts 6
PCB Contact Pattern STAGGERED
Rated Current (Signal) 3A
Contact Resistance 25mOhm
Insulation Resistance 500000000Ohm
Body/Shell Style RECEPTACLE
Dielectric Withstanding Voltage 500VAC V
PCB Contact Row Spacing 9.525 mm
Durability 5000 Cycles
Max Voltage Rating (DC) 30V
Contact Pattern RECTANGULAR
Dimensions
Length 23.7mm
Width 11.2mm
Contact Finish Thickness 30.0μin 0.76μm
Plating Thickness 30μin
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
