DT06-12SD-CE06 image
Favorite
DT06-12SD-CE06 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description DEUTSCH DT06-12SD-CE06 Connector Housing, Thin Wall, Black, DT Series, Plug, 12 Ways, DT Series Socket Contacts
PDF
/
Buying Options
Total Price: USD $6.12
Unit Price: USD $6.1248
≥1 USD $6.1248
≥10 USD $5.53872
≥100 USD $5.232832
≥500 USD $5.105232
≥1000 USD $4.849944
≥3000 USD $4.339421
Inventory: 902
Minimum: 1
-
+

Technical Details

Dimensions

Height 30.94mm
Length 40.5638mm
Width 18.9mm

Compliance

REACH SVHC Unknown
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0

Technical

Serviceable Yes
Hybrid Connector No
Contact Termination Crimp
ELV Compliant
Note Contacts Not Included
Operating Supply Voltage 250V
Empty Shell YES
Body Breadth 0.744 inch
Reference Standard UL
Current Rating 13A
Total Number of Contacts 12
Pitch 4.445mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
Fastening Type Latch Lock
Gender Male
Number of Rows 2
Color Brown
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Number of Positions 12
Connector Type Plug
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature IP68, IP6K9K, Reduced Wire Seals
Series DT
Published 2012
Packaging Bulk

Physical

Housing Material Thermoplastic
Shell Material GLASS FILLED POLYAMIDE
Mounting Type Free Hanging (In-Line)
Mount Socket
Contact Plating Nickel
Contact Material Copper

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 6 Weeks
