776533-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
CONN PLUG ASSY 12PS 18-20AWG GRY
PDF
/
Buying Options
Total Price: USD $4.31
Unit Price: USD $4.312
≥1 USD $4.312
≥10 USD $3.915375
≥100 USD $3.449521
≥500 USD $2.500898
Inventory: 318
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 HB
RoHS Status RoHS Compliant
Dimensions
Width 36.8mm
Length 38.33mm
Height 31.496mm
Technical
Polarized Yes
Hybrid Connector No
Contact Termination Crimp
Note Contacts Not Included
Row Spacing 0.209 (5.30mm)
Housing Color Grey
Depth 40.05mm
Orientation Straight
Pitch 0.177 4.50mm
Contact Type Female Socket
Fastening Type Latch Lock
HTS Code 8536.69.40.30
Gender Male
Number of Rows 2
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Number of Positions 12
Connector Type Plug
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series AMPSEAL 16
Published 2008
Packaging Bulk
Physical
Body Material PBT
Housing Material Thermoplastic
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 2 Weeks
