776434-3
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
CONN CAP ASSY 6POS 14-18AWG YEL
PDF
/
Buying Options
Total Price: USD $2.53
Unit Price: USD $2.5256
≥1 USD $2.5256
≥10 USD $2.29064
≥100 USD $2.169376
≥500 USD $2.11904
≥1000 USD $2.018016
≥3000 USD $1.776474
Inventory: 2298
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 HB
RoHS Status RoHS Compliant
Dimensions
Width 47.55mm
Length 24.6mm
Height 26.6446mm
Technical
Serviceable Yes
Polarized Yes
Hybrid Connector No
Contact Termination Crimp
Note Contacts Not Included
Row Spacing 0.209 (5.30mm)
Housing Color Yellow
Number of Contacts 6
Depth 47.55mm
Orientation Straight
Pitch 0.177 4.50mm
Contact Type Male Pin
Fastening Type Locking Ramp
Gender Receptacle
Number of Rows 2
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Number of Positions 6
Connector Type Receptacle
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series AMPSEAL 16
Published 2008
Packaging Bulk
Physical
Body Material PBT
Housing Material Thermoplastic
Material Thermoplastic
Mounting Type Free Hanging (In-Line)
Mount Free Hanging, Panel
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 4 Weeks
