929505-7 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description Automotive Connectors FF FA-STE-GEH2X11P
PDF
/
Buying Options
Total Price: USD $0.86
Unit Price: USD $0.857324
≥1 USD $0.857324
≥100 USD $0.765421
Inventory: 2218
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Not Applicable
RoHS Status RoHS Compliant
REACH SVHC Unknown

Dimensions

Width 22.3774mm
Length 63.8mm
Height 25.908mm

Technical

Polarized Yes
Hybrid Connector No
Mating Tab Width 2.794mm
Contact Termination Crimp
Circuit Application Signal
ELV Compliant
Note Contacts Not Included
Row Spacing 0.220 (5.60mm)
Empty Shell YES
Current Rating 30A
Depth 26mm
Orientation Straight
Total Number of Contacts 22
Pitch 0.197 5.00mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Tab
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Fastening Type Locking Ramp
Gender Male
Number of Rows 2
Color Black
Number of Positions 22
Connector Type Plug
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Junior Power Timer
Published 2009
Packaging Bulk

Physical

Body Material PBT
Housing Material Polybutylene
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 15 Weeks
