926309-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
Pin & Socket Connectors 10P UNIV.M-N-L.CAP
PDF
/
Inventory: 2091
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Dimensions
Panel Thickness 2.29mm
Length 69.9mm
Technical
VDE Tested Yes
Contact Retention Without
Number of Signal Positions 0
Contact Termination Crimp
Sealable No
Max Voltage Rating (AC) 600V
ELV Compliant
Note Contacts Not Included
Operating Supply Voltage 600V
Empty Shell YES
UL Flammability Code 94V-2
Contact Gender MALE AND/OR FEMALE
Number of Contacts 10
Approval Agency CSA
Current Rating 15A
Depth 27.4mm
Orientation Straight
Pitch 6.35mm
Mixed Contacts NO
Contact Type Male or Female
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Fastening Type Locking Ramp
Voltage - Rated 600V
Number of Rows 1
Color Natural
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Connector Type Receptacle
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series Universal MATE-N-LOK
Published 2008
Packaging Bulk
Physical
Housing Material Nylon
Mounting Type Panel Mount
Mount Panel
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 13 Weeks
