917241-6
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
CONN HOUSING TAB 12POS DUAL PANL
PDF
/
Buying Options
Total Price: USD $3.19
Unit Price: USD $3.1944
≥1 USD $3.1944
≥10 USD $2.84416
≥100 USD $2.525248
≥500 USD $2.07533
Inventory: 952
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 21.5138mm
Length 52mm
Height 33.6mm
Technical
VDE Tested No
Preloaded No
Halogen Free Halogen Free
Contact Termination Crimp
Sealable No
Wire/Cable Gauge 16 AWG
Max Voltage Rating (AC) 600V
ELV Compliant
Note Contacts Not Included
Row Spacing 0.200 (5.08mm)
Operating Supply Voltage 600V
Housing Color Black
Number of Contacts 12
Approval Agency UL
Depth 33.6mm
Orientation Straight
Pitch 0.200 5.08mm
Contact Type Male Pin
Gender Male
Number of Rows 2
Color Black
Min Operating Temperature -67°C
Max Operating Temperature 221°C
Number of Positions 12
Connector Type Plug
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Dynamic D-3500
Published 2007
Packaging Bulk
Physical
Housing Material Polyester
Number of Pins 12
Mounting Type Panel Mount
Mount Cable, Panel
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 17 Weeks
