794953-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
CONN PLUG 2POS PANEL MOUNT
PDF
/
Buying Options
Total Price: USD $0.19
Unit Price: USD $0.1936
≥1 USD $0.1936
≥10 USD $0.16104
≥100 USD $0.117709
≥500 USD $0.11154
≥1000 USD $0.093544
≥3000 USD $0.082236
Inventory: 11803
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Dimensions
Width 23.876mm
Length 5.4102mm
Height 9.6mm
Technical
Contact Retention Without
Insulation Diameter 3.0988 mm
Contact Termination Crimp
Sealable No
Wire/Cable Type Discrete
Dielectric Withstanding Voltage 1500VAC V
Polarization Key POLARIZED HOUSING
Max Voltage Rating (AC) 600V
ELV Compliant
Note Contacts Not Included
Row Spacing 0.165 (4.20mm)
Contact Resistance 10mOhm
Rated Current (Signal) 9A
Operating Supply Voltage 600V
Housing Color Natural, Black
Contact Gender Male
Body Breadth 0.38 inch
Number of Contacts 2
Number Of PCB Rows 2
Approval Agency CSA
Reliability COMMERCIAL
Current Rating 9A
Depth 23.9mm
Orientation Straight
Pitch 4.2mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Male Pin
Filter Feature NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Voltage - Rated 600V
Number of Rows 2
Color Natural
Min Operating Temperature -40°C
Max Operating Temperature 221°C
Connector Type Plug
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series VAL-U-LOK
Published 2002
Packaging Bulk
Physical
Housing Material Nylon
Mounting Type Panel Mount, Snap-In
Mount Panel
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 16 Weeks
