794714-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
CONN CAP RCPT 6POS UMNL FLANGE
PDF
/
Buying Options
Total Price: USD $1.08
Unit Price: USD $1.0824
≥1 USD $1.0824
≥10 USD $0.99088
≥100 USD $0.961312
≥500 USD $0.951632
≥1000 USD $0.883344
≥3000 USD $0.868666
Inventory: 10189
Minimum: 1
-
+
Technical Details
Technical
IEC Conformance NO
Filter Feature NO
Contact Type Male or Female
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 6.35mm
Orientation Straight
Depth 27.43mm
Current Rating 19A
Approval Agency CSA
Number of Contacts 6
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender Female
UL Flammability Code 94V-2
Empty Shell NO
Operating Supply Voltage 600V
Row Spacing 0.250 (6.35mm)
Note Contacts Not Included
ELV Compliant
Max Voltage Rating (AC) 600V
Wire Gauge (Max) 30 AWG
Wire Gauge (Min) 10 AWG
Max Voltage Rating (DC) 600V
Sealable No
Contact Termination Crimp
Contact Retention Without
DIN Conformance NO
MIL Conformance NO
Fastening Type Locking Ramp
Additional Feature MATE-N-LOK, POLARIZATION AVAILABLE
Voltage - Rated 600V
Number of Rows 3
Color Natural
Min Operating Temperature -67°C
Max Operating Temperature 221°C
Connector Type Receptacle
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series Universal MATE-N-LOK
Published 2007
Packaging Bulk
Dimensions
Length 50.8mm
Width 50.8mm
Panel Thickness 2.29mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
Flammability Rating UL94 V-2
Physical
Housing Material Nylon
Shell Material POLYAMIDE
Mounting Type Panel Mount, Twist and Lock
Mount Panel
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 7 Weeks
