794550-6
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
Pin & Socket Connectors 06P DUAC PLUG HSG 94V-2 PAN MT
PDF
/
Inventory: 9420
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Panel
Mounting Type Panel Mount, Snap-In
Housing Material Nylon
Technical
Packaging Bulk
Published 2005
Series AMP-DUAC
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Plug
Number of Positions 6
Max Operating Temperature 221°C
Min Operating Temperature -67°C
Color Natural
Number of Rows 2
Voltage - Rated 600V
Fastening Type Locking Ramp
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Male Pin
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.165 4.20mm
Total Number of Contacts 6
Orientation Straight
Depth 23.9mm
Current Rating 9A
Reference Standard UL
Reliability COMMERCIAL
Approval Agency CSA
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender Male
Rated Current (Signal) 9A
Contact Resistance 3mOhm
Insulation Resistance 1000000000Ohm
Row Spacing 0.165 (4.20mm)
Note Contacts Not Included
ELV Compliant
Max Voltage Rating (AC) 600V
Polarization Key POLARIZED HOUSING
Contact Termination Crimp
VDE Tested Yes
Dimensions
Height 11.7mm
Length 13.7922mm
Width 23.876mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-2
Lead Free Not Applicable
