794132-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
CONN RECEPT/CAP 4POS MATE-N-LOK
PDF
/
Buying Options
Total Price: USD $1.94
Unit Price: USD $1.9448
≥1 USD $1.9448
≥10 USD $1.73712
≥100 USD $1.72832
≥500 USD $1.710896
≥1000 USD $1.569744
≥3000 USD $1.560944
Inventory: 2974
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Contact Plating Tin
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material POLYAMIDE
Housing Material Nylon
Technical
Packaging Bulk
Published 1998
Series Commercial MATE-N-LOK
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Receptacle
Max Operating Temperature 221°C
Min Operating Temperature -67°C
Color Natural
Number of Rows 1
Voltage - Rated 250V
Fastening Type Friction Lock
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Male Pin
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.200 5.08mm
Orientation Straight
Depth 23.62mm
Current Rating 19A
Approval Agency CSA
Number of Contacts 4
Contact Gender Female
Empty Shell NO
Operating Supply Voltage 250V
Note Contacts Not Included
ELV Compliant
Max Voltage Rating (AC) 250V
Wire Gauge (Max) 30 AWG
Wire Gauge (Min) 14 AWG
Wire/Cable Gauge 30 AWG
Max Voltage Rating (DC) 250.25kV
Sealable No
Contact Termination Crimp
Contact Retention Without
Dimensions
Height 23.622mm
Length 21.209mm
Width 8.382mm
Compliance
REACH SVHC Unknown
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Not Applicable
