770707-4
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
Headers & Wire Housings 04P SL156 HSG W/LCK RAMP
PDF
/
Inventory: 5421
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Nylon
Technical
Packaging Bulk
Published 2008
Series SL-156
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Receptacle
Number of Positions 4
Color Natural
Number of Rows 1
Fastening Type Locking Ramp
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Female Socket
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.156 3.96mm
Total Number of Contacts 4
Orientation Straight
Reference Standard UL, CSA
Reliability COMMERCIAL
Shrouding No
Body Breadth 0.287 inch
Contact Gender Female
Operating Temperature (Min) -55°C
Body Depth 0.66 inch
Rated Current (Signal) 7A
Contact Resistance 3mOhm
Insulation Resistance 5000000000Ohm
Note Contacts Not Included
ELV Compliant
Polarization Key POLARIZED HOUSING
Contact Termination Crimp
Wire Size (Min) 30 AWG
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Not Applicable
